12548430 TUBE, INJECTION PUMP, OUTLET
Part #: 12548430 ; 603827
NSN: 4710-01-161-0138 ; 4710011610138
Description: TUBE, INJECTION PUMP, OUTLET
| Pos. # | Image | NSN | Part Number | Description |
| 1 |  |
5330-01-150-5944 | 10137486 | GASKET, FUEL INJECTION PUMP |
| 2 |  |
2910-01-434-8597 | DB2831-5079 | PUMP, FUEL, METERING |
| 3 |
|
4710-01-185-6179 | 5741611 | TUBE ASSEMBLY, METAL |
| 4 |  |
5340-01-462-3446 | 14032383 | CLAMP, LOOP |
| 6 |  |
4730-00-871-6729 | 12273192 | CLAMP, HOSE |
| 7 |  |
5305-01-397-6850 | 11502685 | SCREW, CAP, HEX, #10-1.5x20 |
| 8 |  |
5310-01-461-8011 | 12554517 | NUT, PLAIN BARREL |
| 9 |  |
4710-01-460-9630 | 12554094 | TUBE ASSY, METAL |
| 12 |
|
5342-01-130-1141 | 8922216 | CLIP |
| 13 |
|
4710-01-161-0138 | 12548430 | TUBE, METAL |
| 14 |
|
4730-00-014-2432 | 137397 | INVERTED NUT, TUBE |
| 15 |  |
5342-01-250-1098 | 12339491-1 | BOOT |
| 16 |  |
4730-00-908-6292 | MS35842-14 | CLAMP, HOSE |
| 17 |  |
5310-01-462-4459 | 12550863 | NUT, PLAIN, HEX 10-1.5MM |
